Please present sources for your calculations.
Ok. Of course, this is an educated guess, so you can take it as seriously as you wish, but it IS backed by some empirical data.
Our World in Data tells us that currently, about 1.6 billion hectares are used for crops (which includes all possible uses such as food, feed, biofuels, textiles and so on). See Our World in data (though this is now several years out of date, so it may be a little more):
Total cropland area, measured in hectares. Cropland refers to the area defined by the UN Food and Agricultural Organization (FAO) as 'arable land and permanent crops'.
ourworldindata.org
Now, some proportion is utilised for animal feed, but it isn't clear exactly how much. According to the FAO in Mottett et al (2017), the area is about 550 million hectares, though I am unsure of the definition for "feed" crops (for example, soy is a feed crop by FAO definition yet most soy still services human applications, so not ALL soy planted area would be saved by eliminating animal feed). As an aside, NO, 77% of soy is not grown as animal feed only. In fact, 87% or thereabouts is grown to provide both animal feed AND vegetable oil. Of that 86%, about 20% by weight is oil and 80% by weight is meal. The 77% refers to a "by weight" analysis.
So, if we have 1.6 billion Ha under crops and 540 million Ha are used for feed, then around 1 billion Ha are used for human applications. I would discount slightly the area for feed on the basis of what I said about soy - it is classified as feed yet most is used for human applications. If we eliminated the feed market, how much soy would still be needed? We currently have about 100 million Ha of soy, so even if we reduced this by 2/3, it still leaves about 30 million Ha, so total feed use is closer to 520 million Ha. This bumps the total used for human applications up closer to 1.1 billion Ha. If you disagree you need to offer an alternative analysis.
Our World in Data states that about 740 million hectares are used for human food; they got this from Poore & Nemecek (2018).
We should add our 30 million Ha for soy to this, giving us a total of about 770 million Ha for human food. This suggests that cropland area for other than food and feed is about 330 million Ha (1.1 billion less 770 million). I think it is safe to conclude therefore that currently about 330 million hectares are used for non-food applications.
Now we have a baseline, how much crop do we need to replace animals in our diet? Here we have a couple of references which give us some estimates for land use for a vegan diet.
The first is from the Australian CSIRO which estimates that globally, we shouldn't use more than about two billion hectares to grow crops. Currently, we use about 1.6 billion (and possibly more).
Discover the latest in science and innovation with our news stories and media releases.
blog.csiro.au
CSIRO reports that the average Australian uses about .25/Ha of cropland, including animal feed crops. An Australian pursuing a healthy and sustainable diet might reduce this to about .15/Ha of cropland.
The second paper offers a detailed analysis of the opportunity cost of animal foods compared to plant foods and concludes a plant-based system will realise multiple benefits, including a reduction in land area used for agriculture. More useful however is their estimate that a vegan diet would require about .12/Ha of cropland per person in the US. This estimate as far as I can tell is based on a diet that doesn't significantly reduce calories over the standard US diet so it is possible that a healthy vegan diet might use less.
In a rough analysis I conducted a couple of years ago, I concluded that a vegan diet would require about .18/Ha of cropland, interestingly somewhere in the middle of the range of values here. The point is that an average diet right now requires about .1/Ha of cropland for fruit and vegetables, while I have estimated that an additional .08/Ha is required to replace meat and dairy. Given the estimates in these papers, the correct value is somewhere closer to about .02-.05/Ha. Let's go for the lower value of .02/Ha.
8 billion people needing .02/Ha gives us about 160 million Ha.
So, adding this all together. 770 million Ha for human crop food right now, an additional 160 million Ha to replace meat and dairy, plus about 330 million Ha for non-food human applications, gives us a total of around 1.26 billion Ha. Note that this does NOT include any land needed to grow plants to replace other animal product applications (eg leather, wool). So there is likely to be a little more again. Plus, is there allowance for crop failures and so on due to increasing climate volatility? I am not sure, but I am willing to bet we should add a bit more to this. So we have a solid estimate of 1.2-1.3 billion hectares, with potential for this to be closer to 1.3-1.5 billion Ha.
Of course we can also do a direct calculation using the vegan diet footprint from the Shepon paper; that is .12/Ha x 8 billion people which returns about 960 million hectares, add on the 330 million hectares for non-food use and we get 1.260 billion hectares. This is very close to my estimate above, but without seeing how Shepon et al came up with their value, I am inclined to suspect they haven't allowed for a variety of uncertainties. But taken all together, It still turns out that we are going to need somewhere around 1.3 billion hectares and probably a little more.
Not a big reduction in cropland overall. Plus, this area must grow as population increases. Of course, other methods of food production may change this picture substantially (eg precision fermentation of meat/dairy analogs, vertical farming).
My proposition then remains. If we magically replaced tomorrow all animal use by humans for food, fibre etc with plants and maintained the global population with a healthy and sustainable plant-based diet, land area under crops would not decrease by a significant margin. I think it would decrease, but not by as much as people think.
